24 TB Dell Me5012 Storage Array Rack 2U Array 580W 2.2GHz

DELL storage PowerVault ME5 ME5012 2U Array

Dell PowerVault ME5

Optional ME5 expansion enclosures let you scale up to 336 drives or 8PB1. PowerVault ME412 and ME424 expansion enclosures can only be used with either ME5012 or ME5024 base arrays. The ME484 dense expansion enclosure is supported behind any of the ME5 base arrays. A variety of SSD, 10K and NLSAS drives (including FIPS-certified SEDs) are available.

Dell PowerVault ME5 is the new gold standard for entry-level storage, bringing the basic functionality and data services of
mid-to-high-end storage to small and medium enterprises (SMB) at affordable prices. PowerVault ME5 is a significant improvement over previous systems in terms of performance, capacity, and bandwidth without compromising simplicity, functionality, or business results. PowerVault ME5 is designed to solve a number of SMB data storage challenges by reducing complexity, improving performance, supporting higher capacity, and ensuring data protection, it also provides budget stability while supporting a variety of SMB workloads and application environments. If you're looking for raw power, highly scalable capacity, small footprint,and minimalism; if you're an SMB with a limited budget, PowerVault ME5 starting at 2U or 5U is perfect for you. The PowerVault ME5 array is designed with dual active controllers, multi-core processing, and 99.999% availability, providing flash performance and excellent disk economy, making it an ideal solution for SMB high-value workloads.

Product Paramenters

ME5012

* Up to 2.40PB capacity with 9x 2U expansion enclosures
* Up to 5.28PB capacity with 3x 5U expansion enclosures
* SAN/DAS multiple protocols: SAS, FC, iSCSI
* Dual-active controller architecture
* 12Gb SAS backend
* All premium software features included

Base:	PowerVault ME5012 Storage Array
Chassis Format:	All-in-one (single/dual controllers, internal drive bays, networking) with expansion options
Rack Size:	2U
Dimensions:	H: 8.79 cm (3.46 inches) W: 48.30 cm (19.01 inches) D: 61.87mm (24.36 inches)
Weight:	32.00 kg (71.00 lbs) Empty: 4.80 kg (10.56 lbs) without drives
Controllers:	2 hot-swappable per chassis (dual active) Single/dual controller support for 2U Dual controller only support for 5U
Processor:	Intel® Xeon Processor
Internal Storage:	12 x 3.5” drive bays (2.5” drive carriers supported)
System Memory:	16GB per controller
Min/Max Drive Count:	2/264
Max Raw Capacity:	ME5012: 5.28PB (with 3xME484 expansion) ME5012: 1.83PB (with 9xME424 expansion) ME5012: 1.89PB (with 9xME424 expansion) ME5012: 2.40PB (with 9xME412 expansion)
NAS Support:	Supported with NX Series Windows NAS appliance
Storage Media:	SAS and NL-SAS drives; different drive types, transfer rates, rotational speeds can be mixed in the same system: NLSAS 7.2K 3.5”: 4TB, 8TB, 12TB, 16TB, 16TB FIPS, 20TB SAS 10K 2.5”: 1.2TB, 2.4TB, 2.4TB FIPS SSD: 960GB RI, 1.6TB MU, 1.92TB, 3.84TB, 3.84TB FIPS, 7.68TB RI SDD and HDD: FIPS-certified SEDs
Host Interface:	FC, iSCSI (optical or BaseT), SAS
Max 32Gb FC Ports:	8 per array (support auto-negotiate to 16Gb)
Max 25Gb iSCSI Ports:	8 BaseT ports per array (only support auto negotiate to 1Gb)
Max 12Gb SAS Ports:	8 12Gb SAS ports
Max Multi-Protocol Ports:	4 ports 16Gb FC SFP+ 4 ports 10Gb iSCSI SFP+
Max Management Ports:	2 per array (1Gb BASE-T)
Disk Expansion Protocol:	12Gb SAS
Disk Interface Expansion Ports:	2 12Gb SAS (wide-Port) per array (1 port per controller) Up to 9 2U expansion enclosures per 2U base array Up to 3 5U expansion enclosures per 2U base array Up to 3 5U expansion enclosures per 5U base array
Array Configurations:	All-flash, hybrid flash, HDD only arrays
Storage Format:	Native block-level SAN or DAS
Auto-Tiering:	Up to 3 primary (media-based) tiers
RAID Support:	RAID 1, 5, 6, 10, or ADAPT RAID; any combination of RAID levels can exist in single array
ADAPT RAID:	Distributed erasure coding that reduces rebuild times when drive failures occur
Thin Provisioning:	Active by default on all volumes, operates at full performance across all features
Snapshots:	1024 maximum snapshots per array
Replication:	Asynchronous replication via FC or iSCSI – ME4 to ME5; ME5 to ME4; ME5 to ME5 Target/source relationships may be one-to-many or many-to-one
Volume Copy:	Copy complete standalone volumes
Business Continuity:	VMware Site Recovery Manager
Data-At-Rest Encryption:	Self-encrypting drives (SEDs) in SSD or HDD formats Full Disk Encryption (FDE) based on AES-256 Drives certified to FIPS 140-2 Level 2
Key Manager:	Internal controller key management
Management Support:	PowerVault Manager HTML5 GUI elementmanager, CLI, OpenManage Enterprise 3.9
VMware vCenter:	Support VMware vCenter plugin to manage ME5 arrays through vCenter
Scripting:	CLI API Redfish/Swordfish REST API
Supported Host OS:	Windows 2022, 2019 and 2016 RHEL 8.2 and 7.8 SLES 15.2 and 12.5 VMware 7.0 and 6.7 Citrix XenServer 8.x and 7.x
Virtualization Integration:	VMware vSphere (ESXi) vCenter; SRM Microsoft Hyper-V
Power/Wattage:	580W
Heat Dissipation:	1980 BTU
Voltage:	100-240 VAC
Frequency:	50/60 Hz
Operating Temperature:	5°C - 35°C (41°F - 95°F, derated by 1°C per 300mm above 900m)
Non-Operating Temperature:	-40°C to 70°C (-40 to 158°F) Maximum temperature changes in an hour: 20°C
Operating Humidity Ranges (Non-Condensing):	-12°C dew point minimum, 8% to 85% maximum, non-condensing
Non-Operating Humidity Ranges (Non-Condensing):	21°C dew pointmaximum, 5% to 100% maximum, non-condensing

ME5024

* Up to 2.34PB capacity with 9x 2U expansion enclosures
* Up to 5.22PB capacity with 3x 5U expansion enclosures
* SAN/DAS multiple protocols: SAS, FC, iSCSI
* Dual-active controller architecture
* 12Gb SAS backend
* All premium software features included
